Polyester Rolls
Series 55 Anti-microbial
Multi-Layer Design – Series 55 AM rolls consist of 2 distinct layers of media combined with a non-migrating tackifier resulting in more than 75% filtration efficiency on particles 10 microns and greater. The depth loading characteristics of the Series 55 AM media provide quality performance.
Series 65
Multi-Layer Design – Series 65 panels and links consist of 3 distinct layers of media combined with a non-migrating tackifier resulting in more than 80% filtration efficiency on particles 10 microns and greater. The depth loading characteristics of the Series 65 media provide excellent performance.
The FG-Finishing’s Supraloft® Polyester Group consists of non-woven high loft polyester manufactured by Columbus Industries for paint overspray applications. The collection of both rolls and cut pads is available in a wide variety of performance levels and thicknesses – dry or tackified and with or without an anti-microbial additive. Each filter has high holding capacities due to depth-loading characteristics and graduated fiber density. Filter change out is clean, quick and efficient, and a long service life means the filters need to be changed less often. In addition to the polyester overspray media, FG-F also offers other even denser media to capture very fine particles for secondary operations.
SL-100WC
1″ thick, white, dry polyester media. Used primarily in HVAC air filter applications and could be used for medium-duty paint overspray applications or HVAC prefiltration. Meets GACT.
SL-50WBT – MERV 6
5/8″ thick, blue and white tackified polyester air filter media. Made for light-duty commercial HVAC filtration applications where low cost and low pressure drop are most important. Two zones of filtration. Includes antimicrobial fibers.
SL-100WBT – MERV 7
1″ thick, blue and white, tackified polyester air filter media. Ideal for medium to heavy-duty commercial/industrial HVAC filtration applications where performance, low pressure drop and low cost are equally important. Two zones of filtration and MERV 7 rated. Includes antimicrobial fibers.
SL-150WBT – MERV 7
1-3/4″ thick, blue and white, tackified polyester air filter media. Made for medium to heavy-duty commercial HVAC filtration applications where performance and the removal of a wide range of particles is the priority. Two zones of filtration and MERV 8 rated. Includes antimicrobial fibers.
SL-100GTN – MERV 7
1″ thick, green and heavily tackified air filter media. Used primarily in heavy duty commercial/industrial HVAC air filtration applications where performance is the key factor in media application. Made using all prime fibers with a portion being recycled plastic bottles. Has two zones of filtration with a MERV 7 rating. Includes antimicrobial fibers.
SL-100ONT SURE-STOP AM™ – MERV 10
1″ thick, orange/white, needled and heavily tackified air filter media. Used primarily in commercial/industrial HVAC air filtration applications for heavy-duty applications where performance is very important. Has two zones of filtration with a MERV 10 rating. Includes antimicrobial fibers.
SL-125ONT SURE-STOP AM™ – MERV 8
1-1/2″ thick, orange/white, needled and heavily tackified air filter media. Used primarily for commercial/industrial HVAC air filtration for heavy-duty applications where performance is most important. Has two zones of filtration with a MERV 8 rating. Includes antimicrobial fibers
SL-100PSG
1″ thick, green, gradient density, dry media that is designed primarily for paint overspray applications. Made using all prime fibers with a portion being recycled plastic bottles. Has high performance and loading capabilities at a reasonable cost. Has two layers of fiber density allowing depth loading and high efficiency. Over 99% arrestance on some paints. Meets GACT.
Diffusion and POLY-SORB® Activated Carbon Media also available
